| Model | Accuracy | Total length (L) | Flute length (L1) | Diameter (D) | Number of flutes |
|---|---|---|---|---|---|
| M3*0.5 | H2 | 48 | 11 | 3.15 | 3 |
| M4*0.7 | H2 | 53 | 13 | 4 | 3 |
| M5*0.8 | H2 | 58 | 16 | 5 | 3 |
| M6*1 | H2 | 66 | 19 | 6.3 | 3 |
| M8*1.25 | H2 | 72 | 22 | 6.3 | 3 |
| M10*1.25 | H2 | 80 | 24 | 8 | 3 |
| M12*1.75 | H2 | 89 | 29 | 9 | 4 |
| M14*2 | H2 | 95 | 30 | 11.2 | 4 |
| M16*2 | H2 | 102 | 32 | 12.5 | 4 |
download the specification for 1.4117 Stainless Steel of ZEICIN
