ALLOY NEW TYPE MOULD STEEL

Professional production of the following alloy new type mould steel

类型	GB (中国标)	ASTM (美标)	DIN (德标)	JIS (日标)	BS/BSN (标准)	C Carbon	Cr Chromium	Mn Manganese	Si Silicon	Mo Molybdenum	V Vanadium	Co Cobalt	S Sulphur	P Phosphorus	Ni Nickel	Cu	Nb	W	Ti	B
High-grade carbon steel	50#	1050	CK53	S50C	GB/T699	0.47-0.55	≤0.40	0.60-0.90	≤0.40	≤0.10			≤0.045	≤0.045	≤0.40
High-grade carbon steel	45#	1045	C45	S45C	GB/T699-1999	0.42-0.50	≤0.40	0.50-0.80	≤0.40	≤0.10			≤0.045	≤0.045	≤0.40
High-grade carbon steel	60#	1060	C60	S58C	GB/T699-1988	0.57-0.65	≤0.25	0.50-0.80	0.17-0.37				≤0.035	≤0.035	≤0.25	≤0.25
High-grade carbon steel	65Mn		Sl；SM；Type SC；TypDC			0.62-0.70	≤0.25	0.90-1.20	0.17-0.37				≤0.035	≤0.035	≤0.30
High-grade carbon steel	T8A	SK5	TC80	C80W1	JIS G4401	0.80-0.90	≤0.25	0.10-0.50	0.10-0.35				≤0.030	≤0.030	≤0.20	≤0.30
Alloy Steel	5Cr5WMoVSi				GB/T 1299-2000	0.50-0.60	4.75-5.50	0.20-0.50	0.75-1.10	1.15-1.65			≤0.030	≤0.030				1.10-1.50
Alloy Steel	20CrH	5120	20Cr4	SCR420H	JIS G4052 1979SCr420H	0.17-0.23	0.85-1.25	0.55-0.90	0.15-0.35				≤0.030	≤0.030		≤0.30
Alloy Steel	40CrMo4	4140	41CrMo4	SCM440	GB/T 3077-1988	0.38-0.43	0.90-1.20	0.60-0.85	0.15-0.35	0.15-0.30			≤0.03	≤0.03	0.25	≤0.30
Alloy Steel	20CrNiMo	8620	21NiCrMo2	SNCM220	JIS G4053-2016	0.17-0.23	0.40-0.60	0.60-0.90	0.15-0.35	0.15-0.25			≤0.030	≤0.030	0.40-0.70
Alloy Steel	40CrNiMoA	4340		SNCM439	JIS G4053-2003	0.36-0.43	0.60-1.00	0.60-0.90	0.15-0.35	0.15-0.30			≤0.025	≤0.025	1.60-2.00	≤0.025
Alloy Steel	9CrSi				GB/T 1299-1985	0.85-0.95	0.95-1.25	0.30-0.60	1.20-1.60				≤0.03	≤0.03	≤0.25	≤0.30
Alloy Steel	Q345B				GB/T 1591-2008	≤0.20	≤0.30	≤1.70	≤0.50		≤0.15		≤0.035	≤0.035	≤0.50	≤0.30	≤0.07		≤0.20
Alloy Steel	Q235			SS400	GB/T 700-2006	≤0.22		≤1.4	≤0.35				≤0.05	≤0.045
Tool Steel	T8	W1-0.8C	C80W1	SK80	GB/T 1298-1986	0.75-0.84	≤0.25	≤0.40	≤0.35				≤0.020	≤0.030	≤0.20	≤0.30
Tool Steel	T10	T10A	C105W2	SK105/SK95		0.95-1.04	≤0.25	≤0.40	≤0.35	≤0.030			≤0.020	≤0.030	≤0.20	≤0.30
Tool Steel	T12	T72301	1.1663	SK120		1.15-1.24		≤0.40	≤0.35				≤0.030	≤0.035
Cold Work Mould Steel	Cr12Mo1V	D2	X165CrVMo12	SKD11		1.4-1.6	11.5-13.0	≤0.60	≤0.40	0.70-1.20	≤1.00		≤0.030	≤0.030	≤0.25	≤0.30
Cold Work Mould Steel	Cr12Mo1V1	T30402(UNS)	X155CrVMo121	SKD11	BD2	1.40-1.60	11.00-13.00	≤0.60	0.60	0.70-1.20	0.5-1.10	≤1.00	≤0.030	≤0.030
Cold Work Mould Steel	Cr8Mo1VSi			DC53		0.90-1.10	7.50-8.50	0.40max	0.80-1.20	1.80-2.20	0.20-0.50		0.03Max	0.03Max
Cold Work Mould Steel	9CrWMn	O1/T31501	100MnCrW4	SKS3	1.251	0.9-1.0	0.5-1.0	0.9-1.2	≤0.35	0.1-0.2								0.6-0.9
Cold Work Mould Steel	Cr12	D3,1T30403	X210Cr12	SKD1	YB-1957	2.00-2.30	11.50-13.00	≤0.40	≤0.40				≤0.03	≤0.03
Cold Work Mould Steel	Cr8Mo2SiV				GB/T 1299-2014	0.9-1.05	7.50-8.50	0.20-0.50	0.80-1.10	1.80-2.10	0.15-0.35		≤0.025	≤0.03
Hot Work Mould Steel	4Cr5MoSiV1	H13	X40CrMoV5-1(1.2344)	SKD61		0.32-0.42	4.50-5.50	≤0.50	0.8-1.2	1.00-1.50	0.8-1.2		≤0.03	≤0.03
Hot Work Mould Steel		8407				0.32-0.45	4.75-5.50	0.20-0.50	0.80-1.20	1.10-1.75	0.80-1.20		≤0.03	≤0.03
Hot Work Mould Steel	4Cr5MoSiV	H11				0.33-0.43	4.75-5.50	0.20-0.50	0.80-1.20	1.10-1.60	0.30-0.60		0.03	0.03
Hot Work Mould Steel	5CrNiMO	SKT4		55NiCrMoV6	T61206(UNS)(L6)	0.50-0.60	0.60-0.90	1.20-1.60	0.25-0.60	0.15-0.30			≤0.03	≤0.03
Hot Work Mould Steel	3Cr2W8V	T20821		SKD5	30WCrV9	0.30-0.40	2.20-2.70	≤0.40	≤0.40		0.20-0.50		≤0.030	≤0.03				7.50-9.00
Hot Work Mould Steel	FS443	8418				0.35-0.40	4.70-5.20	0.30-0.50	0.30-0.50	2.70-3.30	0.40-0.70		≤0.035	≤0.035
Plastic Mould Steel				S136H		0.28-0.40	16.00-17.00	≤0.8	≤0.8	0.80-1.20			≤0.03	≤0.03	0.80-1.20
Plastic Mould Steel	3Cr17NiMo		1.4122(X39CrMo17-1)		DIN 17400	0.28-0.40	16.00-17.00	≤0.8	≤0.8	0.80-1.20			≤0.03	≤0.03	0.80-1.20
Plastic Mould Steel	S136	420ESR	1.2083	SKS538		0.36-0.45	12.0-14.00	0.5	0.8				≤0.03	≤0.035	≤0.60
Plastic Mould Steel	X38CrMo16	420M	1.2316			0.28-0.40	16.00-17.00	≤0.8	≤0.8	0.80-1.20			≤0.03	≤0.03	0.80-1.20
Plastic Mould Steel	4Cr13	UNS420J2	1.2083	JIS420	GB/T 1220-2007	0.36-0.45	12.00-14.00	≤0.80	≤0.60				≤0.03	≤0.030
Wear-Resistant Steel Plate	NM360			JFE:NK-EH360	GB/T 24186-2009	≤0.25	≤1.4	≤1.30	≤0.70	≤0.50			≤0.010	≤0.025	≤1.00
Wear-Resistant Steel Plate	NM400			JFE:NK-EH400	GB/T 24186-2009	≤0.25	≤1.4	≤1.60	≤0.70	≤0.50			≤0.010	≤0.025	≤1.00					≤0.004
Wear-Resistant Steel Plate	NM450			JFE:NK-EH450	GB/T 24186-2009	≤0.26	≤1.5	≤1.60	≤0.70	≤0.50			≤0.010	≤0.025	≤0.80					≤0.004
Wear-Resistant Steel Plate	NM500			JFE:NK-EH500	GB/T 24186-2009	≤0.38	≤1.20	≤1.70	≤0.70	≤0.65			≤0.010	≤0.020	≤1.00					≤0.004
Wear-Resistant Steel Plate			HARDOX400		EN 10 204-3.1	≤0.22	≤0.80	≤1.60	≤0.7	≤0.25			≤0.010	≤0.025	≤0.50					0.005-0.006
Wear-Resistant Steel Plate			HARDOX450		EN 10 204-3.1	≤0.25	≤0.50	≤1.60	≤0.7	≤0.25			≤0.010	≤0.025	≤0.25					0.004
Wear-Resistant Steel Plate			HARDOX500		EN 10 204-3.1	≤0.29	≤1.00	≤1.60	≤0.7	≤0.25			≤0.010	≤0.025	≤1.00

High-grade carbon steel

65Mn

65Mn low-alloy round steel must have a high elastic limit and high flexural strength ratio to avoid permanent deformation of spring steel under high load. At the same time also requires good hardenability and low sensitivity to decarbonization, so that the elastic limit greatly reduced; As well as good surface quality, in the hot and cold state of easy processing and good heat treatment technology.

#50

#50 steel is a medium carbon high-strength carbon structural steel, after quenching with high strength and hardness, the steel machinability of medium, low cold deformation plasticity, poor weldability, heat treatment without tempering brittleness, but the hardenability is low, the critical diameter in water is 13*30mm, and water quenching has a tendency to crack. This steel is usually used after heat treatment such as normalizing or quenching tempering, or high-frequency surface quenching. No. 50 steel can be hardened to HRC42~46. Therefore, if the surface hardness is needed, and you want to play the superior mechanical properties of No. 50 steel, the surface of No. 50 steel is often carburized and quenched, so that you can get the required surface hardness.

#45

45# steel pipe is usually suitable for seamless steel pipe material, seamless steel pipe is divided into GB8162, GB8163 these two commonly used, but 45# steel only GB8162, 45# is a commonly used material for mechanical processing.he carbon content of 45# steel pipe is about 0.45%, containing a small amount of manganese, silicon, etc., and high-quality carbon structural steel with low sulfur and phosphorus content.

#60

No. 60 steel is hypoeutectoid steel, with high strength, hardness and elasticity, low plasticity when cold deformation, poor machinability, poor welding and hardenability, water quenching has a tendency to crack, and large parts are mostly normalized. No. 60 steel is used to manufacture shafts, spring rings, wheel shafts, various gaskets, cams, steel ropes and other parts with large forces and working under friction conditions, requiring high strength, wear resistance and certain elasticity.
